| BLT-300A |
|
|
Screw Compressor |
| 型號 |
Model |
|
BLT-300A |
| 排氣溫度 |
Displacement temperture |
|
風冷 Air-Cooling:≤環境溫度+15℃ |
| 排氣壓力 |
Working Pressure |
Bar |
0.7/0.8/1.0/1.2 |
| 排氣量 |
Air Displacement |
m3/min |
38.5/37.5/34.1/30.1 |
| 外型尺寸 |
Dimension(L×W×H) |
mm |
3200×2100×2100 |
| 驅動方式 |
Drive method |
|
直聯 Direct |
| 啟動方式 |
Starting method |
|
Y-▲啟動 Starter |
| 冷卻方式 |
Cooling Model |
|
風冷 Air-Cooling |
| 壓縮級數 |
No. of compression stage |
|
單級 Single stage |
| 電源 |
Electricity |
V/ph/Hz |
380、460、3000、6000、10000/3/50、60 |
| 環境溫度 |
Ambient temperture |
|
-5～+45℃ |
| 噪音 |
Noise level |
dB(A) |
75±2 |
| 功率 |
Motor Power |
kw |
220 |
| 潤滑油量 |
Lubricant |
L |
100 |
| 重量 |
Weight |
kg |
5580 |
| 出口管徑 |
Air Outlet pipe Diameter |
Lnch/mm |
DN80 |
| 冷卻水進出口管徑 |
Cooling water import and export caliber |
Lnch/mm |
G2” |
|
|
|
