型號 (Model) |
BLT-75W |
BLT-100W |
BLT-120W |
BLT-150W |
BLT-175W |
BLT-200W |
BLT-300W |
BLT-350W |
BLT-425W |
BLT-475W |
|
排氣量
Free air deliver/
Discharge pressure |
m3/min/MPa |
10.50/0.7 |
13.50/0.7 |
17.10/0.7 |
21.0/0.7 |
24.1/0.7 |
29.0/0.7 |
38.5/0.7 |
45.0/0.7 |
59.0/0.7 |
67.0/0.7 |
|
9.80/0.8 |
13.00/0.8 |
16.90/0.8 |
20.0/0.8 |
23.6/0.8 |
28.5/0.8 |
37.5/0.8 |
43.5/0.8 |
58.0/0.8 |
66.0/0.8 |
|
8.80/1.0 |
11.80/1.0 |
14.60/1.0 |
17.0/1.0 |
20.5/1.0 |
26.5/1.0 |
34.1/1.0 |
39.0/1.0 |
49.0/1.0 |
56.0/1.0 |
|
7.60/1.3 |
10.00/1.3 |
12.60/1.3 |
14.8/1.2 |
17.8/1.2 |
22.5/1.2 |
30.1/1.2 |
35.0/1.2 |
42.0/1.2 |
46.0/1.2 |
|
壓縮機級數 No. of compression stage |
單級 Single stage |
|
環境溫度 Ambient temperature |
-5～+45℃ |
|
冷卻方式 Cooling Model |
水冷 Water-Cooling |
|
進水溫度 Water inlet temperature |
≤32℃ |
|
進水壓力 Water inlet pressure |
0.3～0.35 Mpa |
|
排氣溫度 Discharge temperature |
≤40℃ |
|
潤滑油量 Lubricant |
L |
50 |
75 |
100 |
150 |
|
噪音 Noise Lvel |
dB(A) |
68±2 |
72±2 |
75±2 |
82±2 |
|
驅動方式 Drive method |
皮帶傳動 Multivee belt |
直聯 Direct |
|
電源 Electricity |
V/ph/Hz |
380、460/3/50、60（含國外） |
380、460、3000、6000、10000/3/50、60（含國外） |
|
功率 Power |
Kw |
55 |
75 |
90 |
110 |
132 |
160 |
220 |
250 |
315 |
355 |
|
啟動方式 Starting method |
Y-▲啟動 Starter |
|
外型尺寸
Dimension |
Length |
mm |
1585 |
1585 |
1710 |
2476 |
2476 |
2736 |
3200 |
2886 |
3746 |
3746 |
|
Width |
mm |
1170 |
1170 |
1170 |
1526 |
1526 |
1806 |
2100 |
2086 |
2086 |
2086 |
|
Height |
mm |
1800 |
1800 |
1800 |
1800 |
1800 |
2100 |
2100 |
2100 |
2100 |
2100 |
|
重量 Weight |
kg |
1180 |
1260 |
1450 |
2600 |
2700 |
3500 |
5580 |
4100 |
7000 |
7000 |
|
出口管徑 Water outlet Pipe Diameter (NPT) |
Lnch/mm |
G2” |
G2” |
G2” |
DN65 |
DN65 |
DN65 |
DN80 |
DN80 |
DN125 |
DN125 |
|
冷卻水進出口管徑
Water pipe Diameter (NPT) |
Lnch |
G3/4” |
G3/4” |
G1 1/2” |
G1 1/2” |
G1 1/2” |
G1 1/2” |
G2” |
G2” |
G2” |
G2” |
