| BLT-75W |
|
|
Screw Compressor |
| 型號 |
Model |
|
BLT-75W |
| 排氣溫度 |
Displacement temperture |
|
水冷 Water-cooling:＜40℃ |
| 排氣壓力 |
Working Pressure |
Bar |
0.7/0.8/1.0/1.2 |
| 排氣量 |
Air Displacement |
m3/min |
10.5/9.80/8.80/7.60 |
| 外型尺寸 |
Dimension(L×W×H) |
mm |
1585×1170×1800 |
| 驅動方式 |
Drive method |
|
皮帶傳動 Multivee belt |
| 啟動方式 |
Starting method |
|
Y-▲啟動 Starter |
| 冷卻方式 |
Cooling Model |
|
水冷 Water |
| 壓縮級數 |
No. of compression stage |
|
單級 Single stage |
| 電源 |
Electricity |
V/ph/Hz |
380/3/50 |
| 環境溫度 |
Ambient temperture |
|
-5～+45℃ |
| 噪音 |
Noise level |
dB(A) |
68±2 |
| 功率 |
Motor Power |
kw |
55 |
| 潤滑油量 |
Lubricant |
L |
50 |
| 重量 |
Weight |
kg |
1180 |
| 出口管徑 |
Air Outlet pipe Diameter |
Lnch/mm |
G2” |
| 冷卻水出入口管徑 |
Water Outlet pipe Diameter |
Lnch/mm |
G3/4” |
|
|
|
